Name: SD34 Heavy Crawler Bulldozer, Weichai WP13 Engine, China Stage IV, Dual Power Intelligent Control Dozer
Brand: Shaanxi Jaenter Trading Co.,Ltd
SKU: SD34
Availability: InStock

Home > Products > Earthmoving Machinery >

SD34 Heavy Crawler Bulldozer, Weichai WP13 Engine, China Stage IV, Dual Power Intelligent Control Dozer

Place of Origin:

China

Brand Name:

shatui

Model Number:

SD34

Request A Quote

Product Details

Working Mass (kg):

39000

Ground Pressure (kPa):

95.5

Engine Model:

WP13

Rated Power / Rated Speed (kW/rpm):

269/2000

Overall Dimensions Of The Complete Machine (mm):

9090 × 4117 × 3650

Track Center Distance (mm):

2140

Track Shoe Width (mm):

560(660/710)

Earthing Length (mm):

3150

Fuel Tank (L):

620

Payment & Shipping Terms

Minimum Order Quantity

1 unit

Packaging Details

Bulk and Container

Delivery Time

30 days

Payment Terms

L/C, T/T

RELATED PRODUCTS

0086-15091751923

jaenter@sxjaenter.com

86--15793596713

Contact Now

Product Description

This SD34 crawler bulldozer adopts Weichai WP13 electronically controlled engine complying with China National Stage IV emission standard. Switchable dual-power modes match different loads to save fuel while ensuring sufficient power output.

Proven transmission structure with self-developed core drive components guarantees stable long-term operation. Single-handle electro-hydraulic control greatly lowers operating intensity, together with pilot working control and 8-inch LCD screen with rearview display for safer, smarter construction work.

Parameter Name	SD34-G XL (Extended Version)
Performance Parameters
Working Mass (kg)	39000
Ground Pressure (kPa)	95.5
engine
Engine Model	WP13
Rated Power / Rated Speed (kW/rpm)	269/2000
Overall Dimensions
Overall Dimensions of the Complete Machine (mm)	9090 × 4117 × 3650
Walking performance
Forward Speed (km/h)	F1:0-3.6,F2:0-6.6,F3:0-11.5
Reverse speed (km/h)	R1:0-4.4,R2:0-7.8,R3:0-13.5
Chassis System
Track Center Distance (mm)	2140
Track Shoe Width (mm)	560(660/710)
Earthing Length (mm)	3150
Fuel tank capacity
Fuel Tank (L)	620
Working hydraulic oil tank (L)	128
Working device
Scraper blade type	Straight Tilt Bucket (Semi-U Bucket)
Soil Shoveling Depth (mm)	560
Ripper Type	single tooth
Loosening Depth (mm)	1250
