Place of Origin:
China
Brand Name:
Jaenter
Model Number:
3QGB45-2-40
Contact Us
| Serial Number | name | quantity | unit | parameter | Remark | |
| one. | Asphalt system | |||||
| 1 | High-temperature asphalt box | 1 | tower | 20 T | It is equipped with a 5-7 heat transfer oil heating coil . It has 100 mm thick rock wool insulation and is wrapped with an integrated composite board . | |
| 2 | Asphalt transfer pump | 1 | tower | 3QGB45-2-40 | 5.5 KW, insulated jacketed high-viscosity pump, flow rate: 25 cubic meters per second, pressure: 0.6 MPa. | |
| 3 | Filter | 1 | tower | standard | ||
| two. | Hydraulic tilting feeding system | |||||
| 1 | Radiant Flip Feeder | 3 | tower | 1.4*2.1m | 6-ton hydraulic crane | |
| 2 | Temperature-controlled electric heating system | 3 | set | 1.5 kW | Mechanical temperature control | |
| 3 | Hydraulic power system | 3 | tower | 3kw | Electromagnetic remote control | |
| three. | Area awaiting integration | |||||
| 1. | Melting and cutting coils | 3 | set | 15cm | 5.7 Heat transfer oil heating coil | |
| 2. | Box in the waiting area | 1 | tower | 25 cubic meters | ||
| Four. | Appearance | |||||
| 1 . | panel | 1 | Thickened stainless steel cleanroom panel | |||
| 2 . | logo | 1 | Acrylic client design customization | |||
| five. | frame | |||||
| 1 . | frame | 1 | 10500*2200*25 00 | Frame: 100*100 square tube, 120*60 square tube Base 120*120 square tube | ||
| 2 . | color | black | ||||
| Total power | 25kw | |||||
