Place of Origin:
China
Brand Name:
Roenter
Model Number:
RO-HX2000
Contact Us
Product Features:
(1) An ideal equipment for medium-sized or large-scale marking line operations;
(2) This equipment is of a driver-operated type, reducing the labor intensity of manual operation and enhancing the construction efficiency.
(3) The advanced hydraulic-driven continuously variable speed system can precisely control the speed and make adjustments;
(4) This equipment can perform ordinary hot-melt marking line construction as well as raised oscillation marking line construction, achieving multi-purpose use with one machine.
(5) The microcomputer is automatically controlled by the latest intelligent program controller and a user-friendly control panel;
(6) The width and height of the markings can be set arbitrarily;
(7) The glass bead sacker that synchronizes with the coating application system ensures more uniform and cost-effective distribution of the glass beads;
(8) The coating bucket made of special materials is resistant to high temperatures, corrosion, and does not deform easily.
(9) It enables the marking protrusions to be precisely and accurately drawn, with shapes, heights, spacings, etc. being highly accurate, fully meeting various road conditions requirements and conforming to international standards.
(10) The double-layer insulation material cylinder ensures a longer insulation time for the molten material, reduces fuel consumption, and improves the efficiency of the molten material.
(11) Equipped with warning lights and lighting fixtures makes night construction safer and more convenient.
Technical specifications:
| Engine | 13-18P Gasoline Engine |
| Drivetrain | Imported hydraulic continuously variable transmission |
| Air compressor | 0.036 m³/min |
| Paint bucket volume | 250kg |
| Glass bead box volume | 20L |
| Heating fuel | Liquefied Petroleum Gas |
| Marking device | Pneumatic scraping and marking bucket, standard 150mm |
| Control system | Computer automatic control |
| Travel speed | 0～20Km/h |
| Maximum climbing angle | ＜30° |
| Marking speed | 1000m/h |
| Marking width | 150mm, 200mm, 300mm, 400mm (Configured according to customer requirements) |
| Equipment dimensions (L×W×H) | 2200mm×1300mm×1850mm |
| Equipment weight | 600kg |
