Name: Portable Cement Mixing Plant for Construction Sites
Brand: Shaanxi Jaenter Trading Co.,Ltd
SKU: YDS2000
Availability: InStock

Home > Products > Road Construction Machinery >

Portable Cement Mixing Plant for Construction Sites

Place of Origin:

China

Model Number:

YDS2000

Request A Quote

Portable Cement Mixing Plant for Construction Sites

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

L/C, T/T

RELATED PRODUCTS

0086-15091751923

jaenter@sxjaenter.com

86--15793596713

Contact Now

Product Description

Model YDS2000

<img alt="" src="

3000 Mobile Component Machine

NO. Name Qty. unit Technical parameter 1 Host machine 1 set

Dimensions: 6800*3520*4100mm

Power supply voltage: AC380V, 50Hz

Hopper volume: 2m2

Maximum component size range: 3000*2000*1300mm;

Maximum component weight: 5 tons

Mould flipping angle: 0-180 degrees

Walking speed: 6m/min

Walking motor power: 1.5KW x 2

Turning speed: 6m/min, 360-degree turning

Turning motor power: 1.5KW

Quality guarantee: 1-year warranty

2 Hydraulic pump station 1 set

Hydraulic valve brand: YOULI

Motor power: 22kw Brand: Wannan

Oil tank volume: 250L

Rated pressure: 14Mpa

Flow rate: 96L/min

Quality guarantee: 1-year warranty

3 Pneumatic and water systems 1 set

Brand: DELIXI

Power supply voltage: AC 220V, 50Hz

Motor power: 2.2KW

Air tank volume: 50L

Water tank volume: 30L

Pressure: 0.8MPa

Quality guarantee: 1-year warranty
