Place of Origin:
China
Brand Name:
SHACMAN
Model Number:
X3000
Contact Us
SHACMAN X3000 8x4 25000 Liters Fuel Tank Truck
Technical Parameters
|
Cabin |
Driving type 8x4 LHD | |
| X3000 cab, two seats with one sleeper, A/C | ||
|
Vehicle Main Dimensions |
Overall dimensions (L x W x H)mm | 11800×2550×3 350 |
| Wheel base (mm) | 1800+4575+1400 | |
| Wheel track (front/rear) (mm) | 2036/1860 | |
|
Weight in KGS |
Tare Weight | 16045 |
| Payload | 30000 | |
| Front axles loading capacity | 2x7500 | |
| Rear axles loading capacity | 2x13000 | |
| Max. Driving Speed(km/h) | 90 | |
|
Engine |
Brand | WEICHAI |
| Model | WP10.380E22 | |
|
Type |
4-stroke direct injection , 6-cylinder in-line , turbo-charged and inter-cooled | |
| Horse Power(HP) | 380 HP | |
| Emission standard | Euro Ⅱ | |
|
Gearbox |
10JSD180+QH50, 10 speed forward and 2 reverse gear |
|
| Oil tank | 300 Liters | |
| Tire | 12.00R20 | |
|
Tank specifications |
Size: 25,000 liters, no compartments One European standard aluminium alloy manholes (φ500mm, one set with one breather valve) ,one bottom valve Thickness: 5mm tank and wave-proof board, carbon steel material One tool box under the truck, 2 fire extinguishers Up-loading system Hose holder:2 pics 6m long |
|
|
Pump |
With one pump, the fuel can be pumped in and out. |
|
|
Painting |
complete chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint | |
