Microcomputer Control Universal Testing Machine WAW-1000

Microcomputer Control Universal Testing Machine WAW-1000

Place of Origin:

China

Model Number:

WAW-1000

Contact Us

Request A Quote
Product Details
Product Name:
Microcomputer Control Universal Testing Machine
Piston Limit Stroke:
150mm
Model:
LWT-EA&SS
Name:
Load Wheel Tester For Emulsion Asphalt &Slurry Seal
Power Supply:
220V/50Hz
Test Accuracy:
0.1mm
Test Range:
0-100mm
Wheel Center Angle:
0-90°
Wheel Center Distance:
50mm
Wheel Center Height:
25mm
Wheel Diameter:
90mm
Wheel Hardness:
HRC60
Wheel Load:
0-200N
Wheel Mass:
1.2kg
Wheel Material:
Aluminum Alloy
Wheel Speed:
0-40r/min
Wheel Width:
25mm
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Bulk
Delivery Time
7 days
Payment Terms
L/C, D/A, D/P, T/T
RELATED PRODUCTS
Contact Us
Product Description

Microcomputer Control Universal Testing Machine



MACHINE:Microcomputer Control Universal Testing Machine

MODEL:WAW-1000



The main technical parameters



 Ultimate test force: 1000kN
 Measuring range and measuring range: 0-1000kN
 Relative error of indication value: 1%
 Rated pressure of hydraulic pump: 40MPa
 Tensile limit spacing: 600mm
 Piston limit stroke: 150mm
 Piston diameter: φ250mm
 Tensile deformation: 0-300mm precision 0.01mm; lateral deformation: 0-25mm precision 0.01mm
 Adjustment range of force control speed: 0.005~5%FS/s
 Force control rate: when the rate is <0.05%FS/s, it is within ±2% of the set value; when the rate is ≥0.05%FS/s, it is within ±0.5% of the set value
 Adjustment range of test bench speed: 0.1~250mm/min
 Speed control accuracy of the test bench: within ±0.2% of the set value
 Constant force control range: 0.5%~....FS
 Constant force control accuracy: when the set value is ≥10%FS, it is within ±0.5% of the set value; when the set value is <10%FS, it is within ±1% of  the set value
 Power supply: three-phase 0.75kW
