Environmental protection intelligent asphalt mixing equipment
KDG fast moving asphalt mixing equipment KDG series asphalt mixing equipment is a new type of quick dismantling, quick moving and quick installation asphalt mixing plant developed by Dagang Construction Machinery on the basis of traditional forced intermittent asphalt mixing plant, which is suitable for export, highway maintenance and frequent relocation due to construction.
Main Features of the Equipment No basic installation: The equipment assembly realizes a highly integrated modular design. The assembly parts are pre-installed in the factory, and only the modules need to be assembled on site. The cold batching hopper, drying cylinder, main building, etc. are all equipped with steel structure foundation to realize foundation-less installation.
Save installation time and basic production costs, and improve the efficiency of installation, demolition and transfer. Quick-installation structure design: the batcher realizes the overall transportation and installation design, the hoist realizes the quick-connection mechanism design, the platform and the baffle adopt the folding quick-installation design, and the installation adopts the quick-installation design of the bolt and bolt.
Quick-fit electrical system design: each assembly is equipped with an independent weak current control box and operating room to achieve quick-plug design. The high-power input end is pre-installed in the factory, the output end is snap-in quick-connect design, and each assembly of the air circuit system is pre-installed in the factory to realize the design of quick connection with the air compressor.
The main performance characteristics of environmental protection intelligent asphalt mixing equipment
Intelligent: Equipped with Dagang remote intelligent service platform, users can monitor the working status of the equipment in real time and send and receive relevant data, Dagang company can connect remotely with users to provide users with timely and effective after-sales service.
Environmentally friendly: Feasible environmental protection solutions are proposed for the three major environmental protection problems of dust, flue gas and noise in the asphalt mixing station. Users can add different levels of environmental protection components according to environmental protection requirements to meet the standards of environmental protection requirements.
Upgrade type: The equipment's batcher, dryer, hoist, vibrating screen and weighing system have been fully upgraded, so that the operation is simple, the output is large, the stability is high, and the mixing quality is achieved.
Extended: The equipment reserves interfaces such as additives, warm mixers and thermal regeneration to better adapt to the needs of future processes and construction.
Main technical parameters of the equipment
|Number of batching hoppers||5||5||6|
|Batching bucket single bucket volume (m³)||10||10||15|
|Rated production capacity (t/h)||160||160||240|
|Total installed capacity (kW)||400||400||678|
|Stirring pot capacity (Kg)||2000||2000||3000|
|Dimensions(m) Finished product warehouse capacity (optional) (t)||32*32*20||32*32*20||35*35*21|
|Bag dust removal area (㎡)||-||40||50|
|Number of Asphalt Tanks (pcs)||2||2||3|
|Number of heavy oil tanks (pcs)||1||1||1|
|Heat transfer oil furnace||600,000Kcal||600,000Kcal||800,000Kcal|
